Present at the
Bologna Motor Show for the first time, Fiat Powertrain
Technologies (FPT) exhibited four products that are
outstanding as regards performance, low fuel consumption and
low emissions. Selected from a range that goes from 1 to 40
litres capacity, from 4 to 12 cylinders, and from 20 to 1800
hp, these engines represent the huge variety of types
available: the S-2000, developed by FPT Racing, which won
the Italian and European Rally Championships and the
International Rally Challenge on the Grande Punto; the NEF
400, a new unit on the leading edge of inboard marine
engines; the now famous 1.3 Multijet, ready with the Panda
to accept the challenge of the Lisbon Dakar 2007; the NEF
RACING, benchmark in the engine sector for medium vehicle
road use, it too about to contend with African deserts.
S-2000 ENGINE – FIAT GRANDE PUNTO RALLY
A naturally aspirated two litre engine, four cylinders in
line, 16 valves, capable of delivering a power output of 270
hp at 8000 rpm, torque of 250 Nm at 6750 rpm: these are the
main features of the engine that marked the Fiat Group’s
return to racing. Derived from a production engine, the
S-2000 has been thoroughly modified to transform it into a
concentrate of technology and performance. The exceptional
features of this engine blended perfectly into the Grande
Punto Rally Super2000, enabling Fiat to obtain three
important victories in 2006: the Italian and European Rally
Championships and the International Rally Challenge.
The engine fitted in the competition Fiat Grande Punto Rally was
entirely developed by the FPT Racing division, that sector of Fiat
Powertrain Technologies which is wholly given over to the design,
experimentation, development and production of: racing powertrains; performance kits for petrol and diesel engines;
and special power units for limited series vehicles.
NEF 400 ENGINE – MARINE APPLICATIONS
Innovative technological solutions, high performance, low
acoustic and polluting emissions, compactness, lightness,
reliability and low operating and maintenance costs: these
are the key features of the futuristic NEF 400, a
state-of-the-art engine for marine applications. This
engine’s supreme technical and performance qualities have
been achieved as a result of modern technologies like: the
Common Rail injection system; electronic operation by means
of the EDC (Electronic Diesel Control); and an advanced
architecture which makes for structural strength and drastic
cuts in noisiness and vibrations.
The NEF 400 respects all recent and future regulations in
the marine sector in terms of emissions: IMO-MARPOL,
2003/44/EC, 2004/26/EC, EPA, CCNR. The optimised design of
mechanical components combined with the common rail
injection system and electronic management are ideal as far
as the environment is concerned, while at the same time
highlighting performance and reliability. Finally, the
performance and reliability of the NEF 400 have been
confirmed by its participation in the European “Powerboat
P1-Classe Super Sport” Championship reserved for standard
production boats and engines.
|
|
Selected from a range that goes from 1 to 40 litres
capacity, from 4 to 12 cylinders, and from 20 to
1800 hp, these engines represent the huge variety of
types available from Fiat Powertrain Technologies. |
|
|
|
|
Present at the Bologna Motor Show for the first
time, Fiat Powertrain Technologies (FPT) exhibited
four products that are outstanding as regards
performance, low fuel consumption and low emissions. |
|
|
1.3 MULTIJET ENGINE – FIAT PANDA DAKAR
Winner of the “Diesel Engine of the Year Award 2005” in its
category, this is the smallest 4 cylinder Common Rail on the
market. Compact and technologically sophisticated, its
performance is outstanding, at the very top of its category:
a weight/output ratio of 1.27 kg/hp, specific power output
of 81 hp/l, electronically controlled variable geometry
turbine (VGT), a cooled and electronically controlled EGR
system for the recirculation of exhaust gases, latest
generation common rail injection system.
The 1.3 Multijet was tested for 250,000 km in the very
severest environmental conditions; its extreme sturdiness
means that only minimal maintenance is required and oil
change intervals have been extended from 20,000 to 30,000
km. Exceptional in everyday use, this engine fears no test
and is ready to show off its qualities of sturdiness and
reliability participating, with the Fiat Panda, in the
Lisbon Dakar 2007. The version on display, prepared by the
FPT Racing team, attains the exceptional output of 105 hp at
4500 rpm.
NEF RACING ENGINE – IVECO/ITALDESIGN TRUCK
NEF "Racing" offers the best performance in its category in
terms of torque and power output. It is a 6 cylinder in line
power plant managed entirely by an electronic control unit
that guarantees full monitoring of operations together with
a protection system for extreme usage conditions. The engine
delivers 300 kW (400 hp) of power at 3000 rpm and a torque
of 1200 Nm at 1600 rpm. The technology adopted for its
realisation in terms of architecture and extreme compactness
also makes maintenance operations easier. Its reliability,
tested at great length in the most demanding of conditions,
makes it particularly suitable for the Lisbon Dakar 2007
where it will be mounted on the Iveco/Italdesign truck of
the P&T Racing Team.
FIAT POWERTRAIN TECHNOLOGIES
Two and a half million engines and two million transmissions
produced every year, sales of about 5.5 billion euros, about
19 thousand employees, 16 plants and 10 R&D centres in 8
different countries: these are the numbers that describe
Fiat Powertrain Technologies, the Sector born in March 2005
which brings together all the engine-related activities of
Fiat Auto (Fiat Powertrain), Iveco (Iveco Motors), Centro
Ricerche Fiat and Elasis. With such numbers, FPT is one of
the most significant enterprises in the automotive powertrain sector at
world level.
In FPT about 3000 highly specialised engineers devote their
time to the development and engineering of innovative
technologies: more than 40 patents filed every year confirm
the quality and soundness of this commitment. Thanks to an
enormous range of products and technologies, FPT is able to
meet the most diversified of market demands, guaranteeing
high performance, reliability and efficiency for its
customers.
|
|
|
