Technical
specifications: Grande Punto Abarth 1.4 turbo (155 CV)
Engine
4 cylinders in line, 4 valves per cylinder, 1368 cc
Power: 155 hp at 5500 min
Max torque 206 Nm at 5000 rpm (230 Nm at 3000 rpm in
“sport” mode)
Drive-by-wire accelerator controls with no mechanical
connection
Supercharged with IHI RHF3-P10.5 fixed geometry
turbocharger.
Transmission
6-speed gearbox
Dual hose external gearbox drive.
Suspension and steering
Front with McPherson strut and anti-roll bar
Torsion bar suspension at the rear
|
 |
|
The 4-cylinder 16v engine (1368 cc supercharged with
an IHI fixed geometry turbocharger) delivers 155 hp
at 5500 rpm with a maximum torque of 206 Nm at 5000
rpm. |
|
|
|
|
 |
|
Developed by Abarth’s designers along with the
technicians who produced the Grande Punto Fiat (one of
Europe’s most successful cars), the Grande Punto Abarth
is factory-built, and is subject to all the regulations
and checks applied to standard models. |
|
|
|
|
Lowered sports suspension
Electric power steering with “power boost” mode.
Brakes
Fixed front caliper: Brembo M4x40, dual piston
Ventilated front brake disc ø 305 mm x 28 mm
Rear caliper with piston ø 54 mm
Rear brake disc ø 264 mm x 11 mm.
Bodywork
Deepened front and rear bumpers
Wheels
Aluminium alloys, 7” x 17”
Tyres: 215/45-17
|
|
|
|
