TECHNICAL SPECIFICATION

100 MultiJet

Type code 4HV
No. of cylinders, arrangement 4, in line
Capacity (cc) 2198
Compression ratio 17.5:1
Max EC power: kW (bhp) at rpm 74 (100) at 2900
Max EC torque: Nm (kgm) at rpm 250 (25.5) at 1500
Valve gear: Chain driven, twin overhead camshaft 4 valves per cylinder
Fuel system: MultiJet direct injection, Common Rail, electronically controlled with turbocharger
Ignition: Compression
Transmission
Drive: Front
Clutch: single plate with hydraulic release device
Gearbox: no. of speeds 5 + REVERSE
Reduction ratios 1st 3.727:1; 2nd 1.952:1; 3rd 1.290:1; 4th 0.875:1; 5th 0.647:1; REVERSE 3.154:1; Final drive ratio 4.933:1 (74/15)
Steering: Type rack and pinion with hydraulic power steering
Turning circle m: short wheelbase / medium wheelbase: 11.6 / 12.46; medium long wheelbase / long wheelbase: 13.54 / 14.28
Braking system
Type: Hydraulic with vacuum brake servo acting on 4 wheels. Crossover circuit system with ABS device and integral rear electronic brake force distributor EBD.
Front: disc ∅ mm 280 Ventilated; Rear: disc ∅ mm 280; Brake servo: ∅ 11"
Suspension
Front: Independent MacPherson with wishbones, coil springs, telescopic shock absorbers and antiroll bar
Rear: Rigid axle with longitudinal parabolic leaf springs, double-acting angled telescopic shock absorbers and flexible side blocks.
Wheels
Tyres: 3.0/3.3 Tn 215/70 R15C – 3.5 Tn 225/70 R15C; MAXI 3.5 Tn 215/75 R16C – 4.0 Tn 225/75 R16C
Electrical equipment (12v)
Battery capacity (Ah) 70
Weights - Capacities
Max towable weight (kg) 2000
Tank capacity (litres) 90
Performance: Top speed (km/h) 130 - 140

120 MultiJet

Type code: Sofim FI AE048ID
No. of cylinders, arrangement 4, in line
Capacity (cc) 2287
Compression ratio 19:1
Max EC power: kW (bhp) at rpm 88 (120) at 3600
Max EC torque: Nm (kgm) / rpm 320 (32.6 Kg) at 2000
Valve gear: Belt driven, twin overhead camshaft cam to cam,
chain driven. Hydraulic tappets. 4 valves per cylinder
Fuel system: MultiJet direct injection, Common Rail, electronically controlled with turbocharger
Ignition: Compression
Transmission
Drive: Front
Clutch: single plate with hydraulic release device
Gearbox: no. of speeds 6 + REVERSE
Reduction ratios 1st 3.727:1; 2nd 1.952:1; 3rd 1.290:1; 4th 0.875:1; 5th 0.673:1; 6th 0.585:1; REVERSE 4.083:1; Final drive ratio; 4.222:1 (76/18); 5.231:1 (68/13) Max


Steering: Type rack and pinion with hydraulic power steering
Turning circle m: short wheelbase / medium wheelbase: 11 / 12.46; medium long wheelbase / long wheelbase: 13.54 / 14.28
Braking system
Type
Front: disc ∅ mm 280 Ventilated / Maxi: 300 Ventilated; Rear: disc ∅ mm 280 Maxi: 280/300 (4 t); Brake servo: ∅ 11"
Suspension
Front: Independent MacPherson with wishbones, coil springs, telescopic shock absorbers and antiroll bar
Rear: Rigid axle with longitudinal parabolic leaf springs, double-acting angled telescopic shock absorbers and flexible side blocks.
Wheels
Tyres: 3.0/3.3 Tn 215/70 R15C – 3.5 Tn 225/70 R15C; MAXI 3.5 Tn 215/75 R16C – 4.0 Tn 225/75 R16C
Electrical equipment (12v)
Battery capacity (Ah) 88
Weights - Capacities
Max towable weight (kg) 2500
Tank capacity (litres) 90
Performance: Top speed (km/h) 145 - 155

160 MultiJet Power

Type code: Sofim
No. of cylinders, arrangement 4, in line
Capacity (cc) 2999
Compression ratio 19:1
Max EC power: kW (bhp) at rpm 115.5 Kw (157) at 3500
Max EC torque: Nm (kgm) at rpm 400 (40.8) at 1700
Valve gear: Chain driven, twin overhead camshaft hydraulic tappets, 4 valves per cylinder
Fuel system: MultiJet direct injection, Common Rail, electronically controlled with turbocharger
Ignition: Compression
Transmission
Drive: Front
Clutch: single plate with hydraulic release device
Gearbox: no. of speeds 6 + Reverse
Reduction ratios 1st 4.167:1; 2nd 3.350:1; 3rd 1.462:1; 4th 0.955:1; 5th 0.695:1; 6th 0.552:1; Reverse 4.083:1; Final drive ratio; 4.222:1 (76/18); 4.563:1 (73/16) Max
Steering: Type rack and pinion with hydraulic power steering
Turning circle m: short wheelbase / medium wheelbase: 11 / 12.46; medium long wheelbase / long wheelbase: 13.54 / 14.28
Braking system
Type
Front: disc ∅ mm 280 ventilated / Maxi: 300 ventilated; Rear: disc ∅ mm 280 / Maxi: 280/300 (4 t); Brake servo: ∅ 11"
Suspension
Front: Independent, MacPherson with wishbones, coil springs and antiroll bar
Rear: Rigid axle with longitudinal parabolic leaf springs, double-acting angled telescopic shock absorbers and flexible side blocks
Wheels
Tyres: 3.0/3.3 Tn 215/70 R15C – 3.5 Tn 225/70 R15C; MAXI 3.5 Tn 215/75 R16C – 4.0 Tn 225/75 R16C
Electrical system (12v)
Battery capacity (Ah) 88
Weights - Capacities
Max towable weight (kg) 2500
Tank capacity (litres) 90
Performances: Top speed (km/h) 155 ÷ 165
