TECHNICAL SPECIFICATIONS


1.3 Multijet 16v 105 bhp

No. of cylinders, arrangement 4 cylinders in line, front transverse
Capacity (cc) 1248
Emissions compliance Euro 4
Compression ratio 16.8 +/- 0.4 : 1
Max. power delivery kW (bhp) 77 (105) at rpm 4000
Peak torque Nm (kgm-EC) 200 (20.4) at rpm 1750
Timing
2 overhead camshafts (belt drive with rocker arm control), 4 valves per cylinder
Fuel supply system
Common Rail Multijet direct injection with electronic control unit, turbo and intercooler
Fuel diesel
Transmission
Drive front
Gearbox mechanical
No. of speeds 5 (+ reverse) 1st 3.909; 2nd 2.238; 3rd 1.444; 4th 1.029; 5th 0.767; Reverse 3.909; Final drive 3.563
Wheels
Standard tyres 195/45 R16 84V
Steering system
Steering box 51 mm/g; Turning circle 9.83
Suspension
Front MacPherson; Rear Torsion axle
Brakes
Front discs, dia. mm 257 x 22 (ventilated); Rear discs, dia. mm 240 x 11
Measurements and weights
Length x width x height (mm) 3810 x 1704 x 1510; Wheelbase (mm) 2388; Front/rear track (mm) 1450/1440
Luggage compartment capacity (dm3) 215 / 290
Fuel tank (litres) 47
Kerb weight (kg) 1045
Performance
Top speed (km/h) 177 in 5th
0 to 100 km/h acceleration sec. 10.3
0 a 1000 m acceleration sec. 32.6
Fuel consumption as per EC Directive 1999/100 litres/100 km
- urban cycle/- out of town/- combined cycle/5.7/4.1/ 4.7
CO2 emissions (g/km) 123

1.3 Multijet 16v 90 bhp with DPF

No. of cylinders, arrangement 4 cylinders in line, front transverse
Capacity (cc) 1248
Emissions compliance Euro 4
Compression ratio 17.6 +/- 0.4 : 1
Max. power delivery kW (bhp) 66 (90) at rpm 4000
Peak torque Nm (kgm-EC) 200 (20,4) at rpm 1750
Timing
2 overhead camshafts (belt drive with rocker arm control), 4 valves per cylinder
Fuel supply system
Common Rail Multijet direct injection with electronic control unit, turbo and intercooler
Fuel diesel
Transmission
Drive front
Gearbox mechanical
No. of speeds 5 (+ reverse) 1st 3.909; 2nd 2.238; 3rd 1.444; 4th 1.029; 5th 0.767; Reverse 3.909; Final drive 3.353
Wheels
Standard tyres 195/45 R16 84V
Steering system
Steering box 51 mm/g; Turning circle 9.83
Suspension
Front MacPherson; Rear Torsion axle
Brakes
Front discs, dia. mm 257 x 22 (ventilated); Rear discs, dia. mm 240 x 11
Measurements and weights
Length x width x height (mm) 3810 x 1704 x 1510; Wheelbase (mm) 2388; Front/rear track (mm) 1450/1440
Luggage compartment capacity (dm3) 215 / 290
Fuel tank (litres) 47
Kerb weight (kg) 1045
Performance
Top speed (km/h) 175 in 5th
0 to 100 km/h acceleration sec. 10.5
0 to 1000 m acceleration sec. 33.8
Fuel consumption as per EC Directive 1999/100 litres/100 km


- urban cycle/- out of town/- combined cycle/5.4/3.9/ 4.5
CO2 emissions (g/km) 117

1.4 16v 6M

No. of cylinders, arrangement 4 cylinders in line, front transverse
Capacity (cc) 1368
Emissions compliance Euro 4
Compression ratio 11.0 : 1
Max. power delivery kW (bhp-EC) 70 (95) at rpm 5800
Peak torque Nm (kgm-EC) 128 (13,0) at rpm 4500
Timing 2 overhead camshafts with hydraulic tappets (toothed belt), 4 valves per cylinder
Fuel supply system Multipoint sequential phased electronic injection, combined with returnless ignition system
Fuel unleaded petrol 95 octane (RON)
Transmission
Drive front
Gearbox mechanical
No. of speeds 6 (+ reverse) 1st 3.545; 2nd 2.158; 3rd 1.480; 4th 1.121; 5th 0.921; 6th 0.766; Reverse 3.818; Final drive 4.071
Wheels
Standard tyres 195/45 R16 84V; Steering system
Steering box 51 mm/g
Turning circle 9.83
Suspension
Front MacPherson; Rear Torsion axle
Brakes
Front discs, dia. mm 257 x 22 (ventilated); Rear discs, dia. mm 240 x 11
Measurements and weights
Length x width x height (mm) 3810 x 1704 x 1510; Wheelbase (mm) 2388; Front/rear track (mm) 1450/1440
Luggage compartment capacity (dm3) 215 / 290
Fuel tank (litres) 47
Kerb weight (kg) 980
Performance
Top speed (km/h) 175 in 5th
0 to 100 km/h acceleration sec. 10.9
0 to 1000 m acceleration sec. 33.3
Fuel consumption as per EC Directive 1999/100 litres/100 km
- urban cycle/- out of town/- combined cycle/8.5/5.4/6.6
CO2 emissions (g/km) 155

Engine 1.4 16v DFN

No. of cylinders, arrangement 4 cylinders in line, front transverse
Capacity (cc) 1368
Emissions compliance Euro 4
Compression ratio 11.0 : 1
Max. power delivery kW (bhp-EC) 70 (95) at rpm 5800
Peak torque Nm (kgm-EC) 128 (13,0) at rpm 4500
Timing 2 overhead camshafts with hydraulic tappets (toothed belt), 4 valves per cylinder
Fuel supply system Multipoint sequential phased electronic injection, combined with returnless ignition system
Fuel unleaded petrol 95 octane (RON)
Transmission
Drive front
Gearbox sequential robotised
No. of speeds 5 (+ reverse) 1st 3.545; 2nd 2.158; 3rd 1.480; 4th 1.121; 5th 0.921; Reverse 3.818; Final drive 4.071
Wheels
Standard tyres 195/45 R16 84V
Steering system
Steering box 51 mm/g
Turning circle 9.83
Suspension
Front MacPherson; Rear Torsion axle
Brakes
Front discs, dia. mm 257 x 22 (ventilated); Rear discs, dia. mm 240 x 11
Measurements and weights
Length x width x height (mm) 3810 x 1704 x 1510; Wheelbase (mm) 2388; Front/rear track (mm) 1450/1440
Luggage compartment capacity (dm3) 215 / 290
Fuel tank (litres) 47
Kerb weight (kg) 995
Performance
Top speed (km/h) 175 in 5th
0 to 100 km/h acceleration sec. 10.4
0 to 1000 m acceleration sec. 30.7
Fuel consumption as per EC Directive 1999/100 litres/100 km
- urban cycle/- out of town/- combined cycle/8.2/5.4/ 6.4
CO2 emissions (g/km) 152
