26th October 2002

new models: Alfa Romeo 147 GTA


>>> technical specifications
>>> equipment
>>> colours

Alfa Romeo 147 GTA

Engine
No. of cylinders, layout 6, in 60° V, front transverse
Bore x stroke (mm) 93 x 78
Capacity (cc) 3179
Compression ratio 10.5 : 1
Max. power output EC: kW (bhp) 184 (250)
at rpm 6200
Peak torque EC: Nm (kgm) 300 (30.6)
at rpm 4800
Timing control 2 OHC, per row, hydraulic tappets and variable valve timing (toothed belt), 4 valves per cylinder
Fuel feed Bosch Motronic ME 7.3.1 electronic MPI with selective knock control
Ignition static, electronic digital combined with injection, 2 knock sensors and 6 HT coils fitted in the head
Electrical equipment (12 V)
Battery: capacity (Ah) 60
Generator (A) 140
Transmission
Drive front
Gearbox: 1st 3.500 : 1
2nd 2.235 : 1
3rd 1.520 : 1
4th 1.156 : 1
5th 0.971 : 1
6th 0.818 : 1
Reverse 3.545 : 1
Final drive ratio 3.733 : 1 (56/15)
Wheels
Tyres 225/45 ZR 17
Steering
Steering box rack and pinion with power steering
Turning circle between kerbs (m) 12.1
Suspension
Front independent, dual high wishbone with double trailing arm and anti-roll bar mounted on ball joints
Rear independent, MacPherson struts with transverse levers of different lengths anchored to aluminium cross beams, reaction arms, offset coil springs, and anti-roll bar mounted on ball joints and linked to the shock absorber
Brakes D (disc)
Front: dia. (mm) D 305 (ventilated)
Rear: dia. (mm) D 276
Bodywork - Dimensions
No. of seats / No. of doors 5 /2
Length / Width (mm) 4213 / 1764
Height, unladen (mm) 1412
Wheelbase (mm) 2546
Front/rear track unladen (mm) 1516 / 1504
Boot capacity VDA (dm3) 280
Capacities - Weights
Fuel tank (litres) 63
Kerb weight (DIN) (kg) 1360
Performance
Speed with engine at 1000 rpm in 6th (km/h) 38.2
Top speed (km/h) 246
Acceleration (1 adult + 30 kg):
- 0 to 100 km/h (s)
- 0 to 1000 m (s)

6.3
26.1
Fuel consumption
Fuel consumption as per EC directive 1999/100 (l/100 km):
- urban cycle
- out-of-town cycle
- combined cycle

18.1
8.6
12.1
Emissions control Euro 4
CO2 emissions (g/km) 287

Alfa Romeo 147 GTA

Equipment
  GTA
ASR S
ABS + EBD S
Driver's and passenger airbag S
Front sidebags S
Window bag S
Fire prevention system S
Alfa CODE S
Split folding rear seat (60/40) S
Rear armrest S
Foglights S
Cruise control S
Xenon headlights O
On-board instruments with multifunctional display and trip computer S
Body-coloured heated electric door mirrors (SX aspherical) S
Central locking control with position lights feedback S
Bi-zone climate control system S
Special leather steering wheel (spokes in puma grey) and gear lever knob S
Steering wheel with radio controls S
Steering wheel with radio and phone controls O
RDS radio with CD + 8 speakers + aerial S
Bose® hi-fi system with amplifier and subwoofer O
16" 205/55 alloy wheels, can be fitted with chains O
17" x 7"1/2 alloy wheels and 225/45 tyres (spoked) O
17"x7"1/2 alloy wheels and 225/45 tyres (5-hole design) S
CONNECT Nav+ (radio, CD, colour display, hands-free, dual-band GSM phone, map navigation system, CONNECT button for services, voice controls, phone and voice memo) O
Electric sunroof O
CD-changer in luggage compartment O
Volume-sensing and anti-lift antitheft system  O
Metallic paint O
Iridescent paint O
Headlight washers S
Tyre kit O
Sports configuration seat in cloth S
Sports configuration seat in leather O
Winter Pack O
Climate Pack O
Comfort Pack O
S = standard     O = option

Alfa Romeo 147 GTA

Colours
Alfa 147 GTA (standard upholstery)
Cloth
  Black/Red Black/Blue Black/Silver
NON-METALLIC COLOURS
Alfa Red X - X
Luxor Black X X X
METALLIC
Boreal Green O - O
Cosmos Blue X X X
Metallic Blue O X X
Metallic Grey X X X
Seagull Blue X X X
Sterling Grey X X X
Metallic Black X X X
IRIDESCENT COLOURS
Nuvola White X X X
X = recommended match    O = available match   - = match not available

Alfa 147 GTA (optional upholstery)
Leather
  Single colour Two-tone with Royal Blackside strip
  Royal Black Imola natural-coloured Silverstone Grey Le Mans Blue
NON-METALLIC COLOURS
Alfa Red X X O -
Luxor Black O X X -
METALLIC
Boreal Green X X - O
Cosmos Blue X X X -
Metallic Blue X X O O
Metallic Grey X X X O
Seagull Blue X O - X
Sterling Grey X X - O
Metallic Black X O X O
IRIDESCENT COLOURS
Nuvola White X X - O
X = recommended match    O = available match   - = match not available

Alfa Romeo 147 GTA
