TECHNICAL SPECIFICATIONS


Specifications 1.9 JTS 160 CV
No. of cylinders, layout: 4, in line
Bore x stroke (mm): 86 x 80
Capacity (cc): 1859
Compression ratio: 11,3 : 1
Max. power output kW (bhp-EC): 118 (160)
at rpm: 6500
Peak torque Nm (kgm-EC): 190 (19,4)
at rpm: 4500
Timing (control): 2 OHC (chain), 4 valves per cylinder, electrohydraulic continuous double variable valve timing
Fuel feed: MED 7.6.1 electronic direct injection combined with ignition
Exhaust pipe: single with polished terminal
Transmission: front wheel drive
Gearbox: 1st 3.818 (42/11)
2nd 2.353 (40/17)
3rd 1,571 (55/35)
4th 1,146 (47/41)
5th 0,943 (33/35)
6th 0,861 (31/36)
Reverse 3.545 (39/11)
Final drive ratio: 4.176 (71/17)
Standard tyres basic outfit: 205/55 R 16
Steering
Steering box: rack and pinion with hydraulic power steering
Turning circle between kerbs (m): 11.1
Suspension
Front: high double wishbones
Rear: Multilink system
Brakes D (disc)
Front (mm): D 305 x 28 ventilated, 60 mm floating calliper
Rear (mm): D 278 x 12 solid, combined 38 mm floating calliper
Supplies – Weights
Fuel tank (litres): 70
DIN kerb weight (kg): 1530
Max. towable weight (kg): 1500
Performance
Top speed (km/h): 210
Acceleration (1 adult + 30 kg):
0-100 km/h (sec) 9.9
0-1000 m (sec) 31.3
Fuel consumption - Emissions as per EC directive 1999/100
Fuel consumption (l/100 km):
urban cycle: 12.4
extra-urban cycle: 6.7
combined cycle: 8.8
CO2 emissions (g/km): 209

Specifications 2.2 JTS 185 bhp
No. of cylinders, layout: 4, in line
Bore x stroke (mm): 86 x 94.6
Capacity (cc): 2198
Compression ratio: 11.3 : 1
Max. power output kW (bhp-EC): 136 (185)
at rpm: 6500
Peak torque Nm (kgm-EC): 230 (23.4)
at rpm: 4500
Timing (control): 2 OHC (chain), 4 valves per cylinder, electrohydraulic continuous double variable valve timing
Fuel feed: MED 7.6.1 electronic direct injection combined with ignition
Exhaust pipe: double with separate silencers and chromed terminal
Transmission: front wheel drive
Gearbox: 1st 3.818 (42/11)
2nd 2.353 (40/17)
3rd 1.571 (55/35)
4th 1.146 (47/41)
5th 0.943 (33/35)
6th 0.861 (31/36)
Reverse 3.545 (39/11)
Final drive ratio: 4.176 (71/17)
Standard tyres basic outfit: 215/55 R 16
Steering
Steering box: rack and pinion with hydraulic power steering
Turning circle between kerbs (m): 11.1
Suspension
Front: high double wishbones
Rear: Multilink system
Brakes D (disc)
Front (mm): D 305 x 28 ventilated, 60 mm floating calliper
Rear (mm): D 278 x 12 solid, combined 38 mm floating calliper
Supplies – Weights
Fuel tank (litres): 70
DIN kerb weight (kg): 1540
Max. towable weight (kg): 1500
Performance
Top speed (km/h): 220
Acceleration (1 adult + 30 kg):
0-100 km/h (sec) 9.0
0-1000 m (sec) 30.3
Fuel consumption - Emissions as per EC directive 1999/100
Fuel consumption (l/100 km):
urban cycle: 13.2
extra-urban cycle: 7.3
combined cycle: 9.5
CO2 emissions (g/km): 224

Specifications 3.2 V6 Q4 260 bhp
No. of cylinders, layout: 6, in line
Bore x stroke (mm): 85.6 x 89
Capacity (cc): 3195
Compression ratio: 11.25 : 1
Max. power output kW (bhp-EC): 191 (260)
at rpm: 6200
Peak torque Nm (kgm-EC): 322 (32.8)
at rpm: 4500
Timing (control): 4 OHC (chain), 4 electrohydraulic continuous variable valve timing phasers
Fuel feed: MED 7.6.2 electronic direct injection combined with ignition
Exhaust pipe: double with separate silencers and chromed terminal
Transmission: four wheel drive
Gearbox: 1st 3.917 (47/12)
2nd 2.040 (51/25)
3rd 1.365 (71/52)
4th 1.048 (65/62)
5th 0.846 (44/52)
6th 0.745 (37/50)
Reverse 3.769 (47/12)
Final drive ratio: 3.895 (74/15)
Standard tyres, basic outfit: 225/50 R 17
Steering
Steering box: rack and pinion with hydraulic power steering
Turning circle between kerbs (m): 11.1
Suspension
Front: high double wishbones
Rear: Multilink system
Brakes D (disc)
Front (mm): D 330 x 28 ventilated, 42 mm aluminium radial fixed calliper with 4 pistons
Rear (mm): D 292 x 22 ventilated, 42 mm combined floating calliper
Supplies – Weights
Fuel tank (litres): 70
DIN kerb weight (kg): 1730
Max. towable weight (kg): 1500
Performance
Top speed (km/h): 237
Acceleration (1 adult + 30 kg):
0-100 km/h (sec) 7.2
0-1000 m (sec) 27.9
Fuel consumption - Emissions as per EC directive 1999/100
Fuel consumption (l/100 km):
urban cycle: 17.0
extra-urban cycle: 8.4
combined cycle: 11.6
CO2 emissions (g/km): 275


Specifications 1.9 JTDM 8V 120 bhp
No. of cylinders, layout: 4, in line
Bore x stroke (mm): 82 x 90.4
Capacity (cc): 1910
Compression ratio: 18 : 1
Max. power output kW (bhp-EC): 88 (120)
at rpm: 4000
Peak torque Nm (kgm-EC): 280 (28.6)
at rpm: 2000
Timing (control): 1 OHC (toothed belt) hydraulic tappets, Multijet direct injection with turbo and intercooler
Fuel feed: Bosch EDC 16C39 electronic engine control system
Exhaust pipe: single with polished terminal
Transmission: front wheel drive
Gearbox: 1st 3.818 (42/11)
2nd 2.158 (41/19)
3rd 1.302 (56/43)
4th 0.959 (47/49)
5th 0.744 (32/43)
6th 0.614 (27/44)
Reverse 3.545 (39/11)
Final drive ratio: 3.650 (73/20)
Standard tyres, basic outfit: 215/55 R 16
Steering
Steering box: rack and pinion with hydraulic power steering
Turning circle between kerbs (m): 11.1
Suspension
Front: high wishbones
Rear: Multilink system
Brakes D (disc)
Front (mm): D 305 x 28 ventilated, 60 mm floating callipers
Rear (mm): D 278 x 12 solid, 38 mm combined floating callipers
Supplies – Weights
Fuel tank (litres): 70
DIN kerb weight (kg): 1575
Max. towable weight (kg): 1500
Performance
Top speed (km/h): 190
Acceleration (1 adult + 30 kg):
0-100 km/h (sec) 11.2
0-1000 m (sec) 33.3
Fuel consumption - Emissions as per EC directive 1999/100
Fuel consumption (l/100 km):
urban cycle: 7.9
extra-urban cycle: 4.9
combined cycle: 6.0
CO2 emissions (g/km): 159

Specifications 1.9 JTDM 16V 150 bhp
No. of cylinders, layout: 4, in line
Bore x stroke (mm): 82 x 90.4
Capacity (cc): 1910
Compression ratio: 17.5 : 1
Max. power output kW (bhp-EC): 110 (150)
at rpm: 4000
Peak torque Nm (kgm-EC): 320 (32.6)
at rpm: 2000
Timing (control): 2 OHC (toothed belt) hydraulic tappets, 4 valves per cylinder, Multijet direct injection with turbo and intercooler
Fuel feed: Bosch EDC 16C39 electronic engine control system
Exhaust pipe: single with polished terminal
Transmission: front wheel drive
Gearbox: 1st 3.818 (42/11)
2nd 2.158 (41/19)
3rd 1.302 (56/43)
4th 0.959 (47/49)
5th 0.744 (32/43)
6th 0.614 (27/44)
Reverse 3.545 (39/11)
Final drive ratio: 3.650 (73/20)
Standard tyres, basic outfit: 215/55 R 16
Steering
Steering box: rack and pinion with hydraulic power steering
Turning circle between kerbs (m): 11.1
Suspension
Front: high wishbones
Rear: Multilink system
Brakes D (disc)
Front (mm): D 305 x 28 ventilated, 60 mm floating callipers
Rear (mm): D 278 x 12 solid, 38 mm combined floating callipers
Supplies – Weights
Fuel tank (litres): 70
DIN kerb weight (kg): 1585
Max. towable weight (kg): 1500
Performance
Top speed (km/h): 208
Acceleration (1 adult + 30 kg):
0-100 km/h (sec) 9.6
0-1000 m (sec) 31.3
Fuel consumption - Emissions as per EC directive 1999/100
Fuel consumption (l/100 km):
urban cycle: 8.3
extra-urban cycle: 4.8
combined cycle: 6.1
CO2 emissions (g/km): 162

Specifications 2.4 JTDM 200 bhp
No. of cylinders, layout: 5, in line
Bore x stroke (mm): 82 x 90.4
Capacity (cc): 2387
Compression ratio: 17 : 1
Max. power output kW (bhp-EC): 147 (200)
at rpm: 4000
Peak torque Nm (kgm-EC): 400 (40.8)
at rpm: 2000
Timing (control): 2 OHC (toothed belt), hydraulic tappets, 4 valves per cylinder, Multijet direct injection with turbo and intercooler
Fuel feed: Bosch EDC 16C39 electronic engine control system
Exhaust pipe: double with separate silencers and chromed terminal
Transmission: front wheel drive
Gearbox: 1st 3.917 (47/12)
2nd 2.040 (51/25)
3rd 1.321 (70/53)
4th 0.954 (62/65)
5th 0.755 (40/53)
6th 0.623 (38/61)
Reverse 3.750 (45/12)
Final drive ratio: 3.545 (78/22)
Standard tyres, basic outfit: 225/50 R 17
Steering
Steering box: rack and pinion with hydraulic power steering
Turning circle between kerbs (m): 11.1
Suspension
Front: high wishbones
Rear: Multilink system
Brakes D (disc)
Front (mm): D 330 x 28 ventilated, 42 mm radial fixed callipers with 4 pistons
Rear (mm): D 292 x 22 ventilated, 42 mm combined floating callipers
Supplies – Weights
Fuel tank (litres): 70
DIN kerb weight (kg): 1680
Max. towable weight (kg): 1500
Performance
Top speed (km/h): 226
Acceleration (1 adult + 30 kg):
0-100 km/h (sec) 8.6
0-1000 m (sec) 29.7
Fuel consumption - Emissions as per EC directive 1999/100
Fuel consumption (l/100 km):
urban cycle: 9.4
extra-urban cycle: 5.6
combined cycle: 7.0
CO2 emissions (g/km): 184
