TECHNICAL SPECIFICATION

Engine Fire 1.2 16v

No. of cylinders, arrangement 4, in line

Bore x stroke (mm) 70.8 x 78.86

Capacity (cc) 1242

Compression ratio 10.6 : 1

Max. power output EC: kW (bhp) 59 (80) at rpm 5000

Peak torque EC: Nm (kgm) 114 (11.6) at rpm 4000

Timing (control) 2 OHC with hydraulic tappets (toothed belt), 4 valves per cylinder

Fuel supply phased sequential electronic MPI combined with ignition and no-return system

Nm kgm

Electrical equipment (12V)

Battery: capacity (Ah) 50

Alternator (A) 90

Transmission

Drive front

Gearbox 5 speeds + reverse

Clutch external, self-adjusting hydraulic,

pedal with no idle stroke

1st speed 3.909 : 1

2nd speed 2.158 : 1

3rd speed 1.480 : 1

4th speed 1.121 : 1

5th speed 0.897 : 1

Final drive 3.733 : 1

Wheels

Rims 6 J x 14-40

Tyres 185/65 R14 86T

Steering rack and pinion with electric

power-assisted steering (Dualdrive)

Turning circle between kerbs (m) 10.4

Suspension

Front independent wheel, MacPherson type, with anti-roll bar, telescopic hydraulic shock absorbers

Rear semi-independent wheels connected by torsion beam, telescopic hydraulic shock absorbers

Braking system

Brakes - D (disc) - T (drum)

Front: dia. x thickness (mm) D ventilated 257 x 22

Rear: dia. x thickness (mm) T 203 x 38

Dimensions

No. of seats 5

No. of doors 5

Length (mm) 3930

Width (mm) 1698

Height, unladen (mm) 1660 (1690 with all-purpose bars)

Front track, unladen (mm) 1434

Rear track, unladen (mm) 1424

Wheelbase (mm) 2508

Front overhang (mm) 794

Rear overhang (mm) 628

VDA luggage capacity (dm3) 320 / 1420

Supplies - Weights

Fuel tank (l) 47

DIN kerb weight (kg) 1152

Performance

Top speed (km/h) 163

Acceleration (1 adult + 30 kg):

0 to 100 km/h (s) 13.5

0 to 1000 m (s) 35.0

Fuel consumption as per EC directive 1999/100 (l/100 km)

- urban cycle 8.4

- extra-urban cycle 5.4

- combined cycle 6.5

Emission control

CO2 emissions (g/km) 155

Engine Fire 1.4 16v

No. of cylinders, arrangement 4, in line

Bore x stroke (mm) 72 x 84

Capacity (cc) 1368

Compression ratio 11.0 : 1

Max. power output EC: kW (bhp) 70 (95) at rpm 5800

Peak torque EC: Nm (kgm) 128 (13.0) at rpm 4500

Timing (control) 2 OHC with hydraulic tappets (toothed belt), 4 valves per cylinder

Fuel supply phased sequential electronic MPI combined with ignition and no-return system

Electrical equipment (12V)

Battery: capacity (Ah) 50

Alternator (A) 90

Transmission

Drive front

Gearbox 5 speeds + reverse

Clutch external, self-adjusting hydraulic,

pedal with no idle stroke

1st speed 3.909 : 1

2nd speed 2.158 : 1

3rd speed 1.480 : 1

4th speed 1.121 : 1

5th speed 0.897 : 1

Final drive 3.733 : 1

Wheels

Rims 6 J x 15-40

Tyres 195/60 R15 88T

Steering rack and pinion with electric

power-assisted steering (Dualdrive)

Turning circle between kerbs (m) 10.4

Suspension

Front independent wheel, MacPherson type, with anti-roll bar, telescopic hydraulic shock absorbers

Rear semi-independent wheels connected by torsion beam, telescopic hydraulic shock absorbers

Braking system

Brakes - D (disc) - T (drum)

Front: dia. x thickness (mm) D ventilated 257 x 22

Rear: dia. x thickness (mm) T 203 x 38

Dimensions

No. of seats 5

No. of doors 5

Length (mm) 3930

Width (mm) 1698

Height, unladen (mm) 1660 (1690 with all-purpose bars)

Front track, unladen (mm) 1434

Rear track, unladen (mm) 1424

Wheelbase (mm) 2508

Front overhang (mm) 794

Rear overhang (mm) 628

VDA luggage capacity (dm3) 320 / 1420

Supplies - Weights

Fuel tank (l) 47

DIN kerb weight (kg) 1155

Performance

Top speed (km/h) 175

Acceleration (1 adult + 30 kg):

0 to 100 km/h (s) 11.5

0 to 1000 m (s) 33.0

Fuel consumption as per EC directive 1999/100 (l/100 km)

- urban cycle 8.5

- extra-urban cycle 5.5

- combined cycle 6.6

Emission control

CO2 emissions (g/km) 157

Engine 1.3 16v Multijet

No. of cylinders, arrangement 4, in line

Bore x stroke (mm) 69.6 x 82

Capacity (cc) 1251

Compression ratio 18.0 : 1

Max. power output EC: kW (bhp) 51 (70) at rpm 4000

Peak torque EC: Nm (kgm) 180 (18.3) at rpm 1750

Timing (control) DOHC (toothed belt), 4 valves per cylinder

Fuel supply Multijet Common Rail direct injection with electronic control unit, turbo and intercooler

Electrical equipment (12V)

Battery: capacity (Ah) 50

Alternator (A) 90

Transmission

Drive front

Gearbox 5 speeds + reverse

Clutch external, self-adjusting hydraulic,

pedal with no idle stroke

1st speed 3.909 : 1

2nd speed 2.238 : 1

3rd speed 1.444 : 1

4th speed 1.029 : 1

5th speed 0.767 : 1

Final drive 3.563 : 1

Wheels

Rims 6 J x 15-40

Tyres 195/60 R15 88T

Steering rack and pinion with electric

power-assisted steering (Dualdrive)

Turning circle between kerbs (m) 10.4

Suspension

Front independent wheel, MacPherson type, with anti-roll bar, telescopic hydraulic shock absorbers

Rear semi-independent wheels connected by torsion beam, telescopic hydraulic shock absorbers

Braking system

Brakes - D (disc) - T (drum)

Front: dia. x thickness (mm) D ventilated 257 x 22

Rear: dia. x thickness (mm) T 203 x 38

Dimensions

No. of seats 5

No. of doors 5

Length (mm) 3930

Width (mm) 1698

Height, unladen (mm) 1660 (1690 with all-purpose bars)

Front track, unladen (mm) 1434

Rear track, unladen (mm) 1424

Wheelbase (mm) 2508

Front overhang (mm) 794

Rear overhang (mm) 628

VDA luggage capacity (dm3) 320 / 1420

Supplies - Weights

Fuel tank (l) 47

DIN kerb weight (kg) 1200

Performance

Top speed (km/h) 159

Acceleration (1 adult + 30 kg):

0 to 100 km/h (s) 15.4

0 to 1000 m (s) 36.6

Fuel consumption as per EC directive 1999/100 (l/100 km)

- urban cycle 6.2

- extra-urban cycle 4.5

- combined cycle 5.1

Emission control

CO2 emissions (g/km) 135

Engine 1.9 Multijet

No. of cylinders, arrangement 4, in line

Bore x stroke (mm) 82 x 90.4

Capacity (cc) 1910

Compression ratio 18.0 : 1

Max. power output EC: kW (bhp) 74 (100) at rpm 4000

Peak torque EC: Nm (kgm) 260 (26.4) at rpm 1750

Timing (control) 1 OHC (toothed belt), 2 valves per cylinder

Fuel supply Multijet Common Rail direct injection with electronic control

unit, turbo and intercooler

Electrical equipment (12V)

Battery: capacity (Ah) 60

Alternator (A) 105

Transmission

Drive front

Gearbox 5 speed Getrag + reverse

Clutch external, self-adjusting hydraulic,

pedal with no idle stroke

1st speed 3.577 : 1

2nd speed 1.882 : 1

3rd speed 1.192 : 1

4th speed 0.848 : 1

5th speed 0.686 : 1

Final drive 3.632 : 1

Wheels

Rims 6 J x 15-40

Tyres 195/60 R15 88T

Steering rack and pinion with electric

power-assisted steering (Dualdrive)

Turning circle between kerbs (m) 10.2

Suspension

Front independent wheel, MacPherson type, with anti-roll bar, telescopic hydraulic shock absorbers

Rear semi-independent wheels connected by torsion beam, telescopic hydraulic shock absorbers

Braking system

Brakes - D (disc) - T (drum)

Front: dia. x thickness (mm) D ventilated 284 x 22

Rear: dia. x thickness (mm) T 228 x 40

Dimensions

No. of seats 5

No. of doors 5

Length (mm) 3930

Width (mm) 1698

Height, unladen (mm) 1660 (1690 with all-purpose bars)

Front track, unladen (mm) 1434

Rear track, unladen (mm) 1424

Wheelbase (mm) 2508

Front overhang (mm) 794

Rear overhang (mm) 628

VDA luggage capacity (dm3) 320 / 1420

Supplies - Weights

Fuel tank (l) 47

DIN kerb weight (kg) 1275

Performance

Top speed (km/h) 179

Acceleration (1 adult + 30 kg):

0 to 100 km/h (s) 11.5

0 to 1000 m (s) 33.0

Fuel consumption as per EC directive 1999/100 (l/100 km)

- urban cycle 7.0

- extra-urban cycle 4.7

- combined cycle 5.5

Emission control

CO2 emissions (g/km) 146
