TECHNICAL SPECIFICATION - DOBLÒ


ENGINE 1.4 8v (ACTUAL - ACTIVE - DYNAMIC - FAMILY)

No. cylinders, arrangement 4, in line, front, transverse
Bore x stroke (mm) 72 x 84 mm
Capacity (cc) 1368
Emission level Euro 4
Compression ratio 11.1:1
Max EC power: kW (bhp) at rpm 57 (77) 6000
Max EC power: Nm (kgm) RPM 115 (11.7) 3000
Timing (drive) 1 OHC (toothed belt) with hydraulic tappets
Fuel Unleaded fuel (95 RON)
Fuel system Electronic MPI with phased sequential injection, returnless system; Ignition static electronic integral with injection

TRANSMISSION
Drive front
Clutch single dry plate with cup engagement spring, hydraulic control
Gearbox: no. gears 5 + reverse

STEERING
Type rack and pinion with power steering
Turning circle (between pavements) 10.5

BRAKES – D (disc) - T (drum)
Type hydraulic system with 2 independent crossover circuits; front disc
brakes; rear drum brakes
Front: dia. mm D 284 ventilated; Rear: dia. mm T 228
Brake servo: Ø 10”

SUSPENSION
Front independent MacPherson type with tie rods anchored to a subframe, telescopic hydraulic shock absorbers, coil springs and stabiliser bar
Rear rigid axle with longitudinal leaf springs

WHEELS
Tyres 185/65 R 15

ELECTRICAL EQUIPMENT (12v)
capacity (Ah) 40

CAPACITIES
Fuel tank capacity (litres) 60

PERFORMANCE – FUEL CONSUMPTION
Top speed (km/h) 148/145*/145**
Fuel consumption (EC Directive 99/100)
urban cycle (l/100 km) 9.2/9.4*/9.2**
extra-urban cycle (l/100 km) 6.3/6.5*/6.3**
combined (l/100 km) 7.4/7.6*/7.4**
CO2 exhaust emissions (g/km) 174/178*/174**

DIMENSIONS
Wheelbase (mm) 2583
Length (mm) 4253
Width (mm) 1722
Max unladen height (mm) 1818
Front track (mm) 1514
Rear track (mm) 1505
Front overhang 833
Rear overhang 837
Luggage compartment capacity (dm3) 750 / 3000

WEIGHTS
Vehicle kerb weight (with tanks full, spare wheel, tools and
accessories) (kg) 1230/1250*/1320**
Payload including driver (kg) 600
Towable loads (kg) - braked trailer 1000; unbraked trailer 500
* High top version **Family version

ENGINE 1.6 Natural Power (ACTIVE)

No. cylinders, arrangement 4, in line, front, transverse
Bore x stroke (mm) 80.5 x 78.4 mm
Capacity (cc) 1596
Emission level Euro 4
Compression ratio 10.5:1
Max EC power: kW (bhp) 76 (103) 5750 (petrol) at rpm 68 (92) 5750 (methane)
Max EC power: Nm (kgm) 145 (14.8) 4000 (petrol) RPM 130 (13.2) 4000 (methane)
Timing (drive) 2 OHC (toothed belt)
Fuel Unleaded fuel (95 RON) / methane
Fuel system Phased sequential electronic MPI, dual fuel system with special injectors for methane; Ignition electronic, static, integrated

TRANSMISSION
Drive front
Clutch single dry plate with cup engagement spring, hydraulic control
Gearbox: no. gears 5 + reverse

STEERING
Type rack and pinion with power steering
Turning circle (between pavements) 10.5

BRAKES – D (disc) - T (drum)
Type hydraulic system with 2 independent crossover circuits; front disc
brakes; rear drum brakes
Front: dia. mm D 284 ventilated; Rear: dia. mm T 228
Brake servo: Ø 10”

SUSPENSION
Front independent MacPherson type with tie rods anchored to a subframe, telescopic hydraulic shock absorbers, coil springs and stabiliser bar
Rear rigid axle with longitudinal leaf springs

WHEELS
Tyres 175/70 R 14

ELECTRICAL EQUIPMENT (12v)
Battery capacity (Ah) 50

CAPACITIES
Fuel tank capacity (litres) 30 (petrol)
30.9 m3 (21 kg) (methane)

PERFORMANCE – FUEL CONSUMPTION Petrol Methane
Top speed (km/h) 163 154
Fuel consumption (EC Directive 99/100) (l/100 km) (m3/100 km - kg/100 km)
urban cycle (l/100 km) 11.9 11.7 – 8.2
extra-urban cycle (l/100 km) 7.6 7.4 – 5.2
combined (l/100 km) 9.2 9 – 6.3
CO2 exhaust emissions (g/km) 218 171

DIMENSIONS
Wheelbase (mm) 2583
Length (mm) 4253
Width (mm) 1722
Max unladen height (mm) 1818
Front track (mm) 1514
Rear track (mm) 1505
Front overhang 833
Rear overhang 837
Luggage compartment capacity (dm3) 530

WEIGHTS
Vehicle kerb weight (with tanks full, spare wheel, tools and
accessories) (kg) 1445
Payload including driver (kg) 485
Towable loads (kg) - braked trailer 1300; unbraked trailer 500

ENGINE 1.3 Multijet 16v (ACTUAL - ACTIVE - DYNAMIC - FAMILY)

No. cylinders, arrangement 4, in line, front, transverse
Bore x stroke (mm) 69.8 x 82 mm
Capacity (cc) 1248
Emission level Euro 4 with particulate filter
Compression ratio 17.6:1
Max EC power: kW (bhp) at rpm 62 (85) 4000
Max EC power: Nm (kgm RPM 200 (20.4) 1750
Timing (drive) 2 OHC (chain) with hydraulic tappets
Fuel diesel
Fuel system Common Rail Multijet electronic direct injection with turbocharger and intercooler; Ignition by compression

TRANSMISSION
Drive front
Clutch single dry plate with cup engagement spring, hydraulic control
Gearbox: no. gears 5 + reverse

STEERING
Type rack and pinion with power steering
Turning circle (between pavements) 10.5

BRAKES – D (disc) - T (drum)
Type hydraulic system with 2 independent crossover circuits; front disc
brakes; rear drum brakes
Front: dia. mm D 284 ventilated; Rear: dia. mm T 228
Brake servo: Ø 10”

SUSPENSION


Front independent MacPherson type with tie rods anchored to a subframe, telescopic hydraulic shock absorbers, coil springs and stabiliser bar
Rear rigid axle with longitudinal leaf springs

WHEELS
Tyres 185/65 R 15

ELECTRICAL EQUIPMENT (12v)
Battery capacity (Ah) 50

CAPACITIES
Fuel tank capacity (litres) 60

PERFORMANCE – FUEL CONSUMPTION
Top speed (km/h) 156/153*/153**
Fuel consumption (EC Directive 99/100)
urban cycle (l/100 km) 6.7/6.8*/6.7**
extra-urban cycle (l/100 km) 4.8/4.9*/4.8**
combined (l/100 km) 5.5/5.6*/5.5**
CO2 exhaust emissions (g/km) 145/148*/145**

DIMENSIONS
Wheelbase (mm) 2583
Length (mm) 4253
Width (mm) 1722
Max unladen height (mm) 1818
Front track (mm) 1514
Rear track (mm) 1505
Front overhang 833
Rear overhang 837
Luggage compartment capacity (dm3) 750 / 3000

WEIGHTS
Vehicle kerb weight (with tanks full, spare wheel, tools and
accessories) (kg) 1330/1350*/1420**
Payload including driver (kg) 600
Towable loads (kg) - braked trailer 1300; unbraked trailer 500
* High top version **Family version

ENGINE 1.9 Multijet 16v (ACTIVE - DYNAMIC)

No. cylinders, arrangement 4, in line, front, transverse
Bore x stroke (mm) 82 x 90.4 mm
Capacity (cc) 1910
Emission level Euro 4
Compression ratio 18.0:1
Max EC power: kW (bhp) at rpm 77 (105) 4000
Max EC power: Nm (kgm) RPM 200 (20.4) 1750
Timing (drive) 1 OHC (toothed belt)
Fuel diesel
Fuel system Common Rail Multijet electronic direct injection with turbocharger and intercooler; Ignition by compression

TRANSMISSION
Drive front
Clutch single dry plate with cup engagement spring, hydraulic control
Gearbox: no. gears 5 + reverse

STEERING
Type rack and pinion with power steering
Turning circle (between pavements) 10.5

BRAKES – D (disc) - T (drum)
Type hydraulic system with 2 independent crossover circuits; front disc
brakes; rear drum brakes
Front: dia. mm D 284 ventilated; Rear: dia. mm T 228
Brake servo: Ø 10”

SUSPENSION
Front independent MacPherson type with tie rods anchored to a subframe, telescopic hydraulic shock absorbers, coil springs and stabiliser bar
Rear rigid axle with longitudinal leaf springs

WHEELS
Tyres 185/65 R 15

ELECTRICAL EQUIPMENT (12v)
Battery capacity (Ah) 60

CAPACITIES
Fuel tank capacity (litres) 60

PERFORMANCE – FUEL CONSUMPTION
Top speed (km/h) 164
Fuel consumption (EC Directive 99/100)
urban cycle (l/100 km) 7.5
extra-urban cycle (l/100 km) 4.8
combined (l/100 km) 5.8
CO2 exhaust emissions (g/km) 153

DIMENSIONS
Wheelbase (mm) 2583
Length (mm) 4253
Width (mm) 1722
Max unladen height (mm) 1818
Front track (mm) 1514
Rear track (mm) 1505
Front overhang 833
Rear overhang 837
Luggage compartment capacity (dm3) 750 / 3000

WEIGHTS
Vehicle kerb weight (with tanks full, spare wheel, tools and
accessories) (kg) 1320
Payload including driver (kg) 600
Towable loads (kg) - braked trailer 1300; unbraked trailer 500

ENGINE 1.9 Multijet 8v (ACTIVE - DYNAMIC- FAMILY)

No. cylinders, arrangement 4, in line, front, transverse
Bore x stroke (mm) 82 x 90.4 mm
Capacity (cc) 1910
Emission level Euro 4 with particulate filter
Compression ratio 18.0:1
Max EC power: kW (bhp) at rpm 88 (120) 4000
Max EC power: Nm (kgm) RPM 200 (20.4) 1750
Timing (drive) 1 OHC (toothed belt)
Fuel diesel
Fuel system Common Rail Multijet electronic direct injection with turbocharger and intercooler; Ignition by compression

TRANSMISSION
Drive front
Clutch single dry plate with cup engagement spring, hydraulic control
Gearbox: no. gears 5 + reverse

STEERING
Type rack and pinion with power steering
Turning circle (between pavements) 10.5

BRAKES – D (disc) - T (drum)
Type hydraulic system with 2 independent crossover circuits; front disc
brakes; rear drum brakes
Front: dia. mm D 284 ventilated; Rear: dia. mm T 228
Brake servo: Ø 10”

SUSPENSION
Front independent MacPherson type with tie rods anchored to a subframe, telescopic hydraulic shock absorbers, coil springs and stabiliser bar
Rear rigid axle with longitudinal leaf springs

WHEELS
Tyres 185/65 R 15

ELECTRICAL EQUIPMENT (12v)
Battery capacity (Ah) 60

CAPACITIES
Fuel tank capacity (litres) 60

PERFORMANCE – FUEL CONSUMPTION
Top speed (km/h) 177/174*/174**
Fuel consumption (EC Directive 99/100)
urban cycle (l/100 km) 7.5/7.7*/7.5**
extra-urban cycle (l/100 km) 5.2/5.3*/5.2**
combined (l/100 km) 6.1/6.2*/6.1**
CO2 exhaust emissions (g/km) 160/163*/160**

DIMENSIONS
Wheelbase (mm) 2583
Length (mm) 4253
Width (mm) 1722
Max unladen height (mm) 1818
Front track (mm) 1514
Rear track (mm) 1505
Front overhang 833
Rear overhang 837
Luggage compartment capacity (dm3) 750 / 3000

WEIGHTS
Vehicle kerb weight (with tanks full, spare wheel, tools and
accessories) (kg) 1340/1360*/1430**
Payload including driver (kg) 600
Towable loads (kg)
braked trailer 1300
unbraked trailer 500

* High top version **Family version New Doblò * Unladen
