Engine 1.2 Fire
No. of cylinders, arrangement 4, in line, front, transverse
Bore x stroke (mm) 70.8 x 78.86
Capacity (cc) 1242
Compression ratio 9.8 : 1
Max. power output EC: kW (bhp) 44 (60)
at rpm 5000
Peak torque EC: Nm (kgm) 102 (10.4)
at rpm 2500
Timing 1 OHC with mechanical tappets
Fuel supply phased sequential electronic MPI
Ignition electronic, static advance combined with injection

Electrical equipment (12V)
Battery: capacity (Ah) 40

Transmission
Drive front
1st speed 3.909 : 1
2nd speed 2.158 : 1
3rd speed 1.480 : 1
4th speed 1.121 : 1
5th speed 0.897 : 1
Reverse 3.818 : 1
Final drive 3.438 : 1 (55/16)

Wheels
Tyres 155/80 R13 (Dynamic)
165/65 R14 (Emotion - opt. on Dynamic)

Steering rack and pinion with electric power steering
Turning circle between kerbs (m) 9.1

Suspension
Front independent MacPherson type with transverse lower wishbones
anchored to an auxiliary cross-beam; stabiliser bar connected to
the shock absorber
Rear wheels connected by torsion beam

Braking system
Brakes - D (disc) - T (drum)
Front (mm) D 240 Rear (mm) T 180

Dimensions
No. of seats 4 (5 opt.) No. of doors 5
Length (mm) 3538 Width (mm) 1578 - 1589* Height, unladen (mm) 1540 - 1578**
Wheelbase (mm) 2299
Front track (mm) 1366 - 1372*** Rear track (mm) 1357 - 1363***
VDA luggage capacity (dm3) 206 / 775

Supplies - Weights
Fuel tank (litres) 35
DIN kerb weight (kg) 860
Payload including driver (kg) 465
Max. towable weight (kg) 800

Performance
Top speed (km/h) 155
Acceleration: (2 adults + 20 kg)
0 to 100 km/h (s) 14
0 to 1000 m (s) 36

Fuel consumption as per EC directive 1999/100 (l/100 km)
- urban cycle 7.1 / 6.8 ****
- extra-urban cycle 4.8 / 4.6 ****
- combined cycle 5.6 / 4.6 ****

Emissions control
CO2 emissions (g/km) 133 / 127 ****

* with rubbing strips
** with all-purpose bars
*** depending on the tyres adopted
**** with Dualogic
